Skoda Felicia 450
![]() | |
Manufacturer | AZNP |
Production | 1959 to 1964 |
Class | Sports |
Body style | 2-door convertible |
Layout | front engine, rear wheel drive |
Engine | 1.1 L I4, 1.2 L I4 |
Wheel base | 94.56 in, 2400 mm |
Length | 160.16 in, 4065 mm |
Width | 63.04 in, 1600 mm |
Height | 56.33 in, 1380 mm |
The Skoda Felicia and 450 is an open convertible automobile which was produced by AZNP from 1957 to 1964.
History
The Skoda 450 or Skoda Felicia was a rear wheel drive convertible with two doors and 2 + 2 seats seats produced by the Czechoslovak (today Czech) car manufacturer AZNP under the brand name Skoda.
The 450 was produced between 1957 and 1964 and was based on the Škoda 440. The 450 was distinguished from the sedan and combi by a more powerful engine and a fabric roof. From about 1960 a hardtop was available as a extra, which made the Felicia suitable for all weather conditions.
The 450 was made from 1957 through 1959 with a four-cylinder engine with 1089 cc and 50 hp (37 kW). With this engine, the Škoda 450 could reach a top speed of 135 km/h fitted with a 4 speed gearbox.The suspension at front was independent, wishbones, coil springs, anti-roll bar and telescopic dampers the rear suspension fitted with swinging semi-axles, laminated transverse upper arms and telescopic dampers.
In 1959 the name 450 was changed to Škoda Felicia after a modernization and some external changes. The 450 was built as Felicia until 1964. From 1961 a version with a 1221 cc 55 hp engine was also produced as Škoda Felicia Super.
The Felicia was introduced in 1959 as a 2-door convertible, replacing the Škoda 450. Able to seat five persons, it was equipped with a folding hood and a plastic hardtop. Styling is similar to that of the contemporary Škoda Octavia. The Felicia was offered only with a 1089 cc four-cylinder engine however a Felicia Super model was introduced in 1961 powered by a larger 1221 cc with 2 Jikov 32 SOPc downdraft carburettors .
PERFORMANCE: 1200cc Super
- Engine capacity: 74.68 cu in, 1221 cu cm
- Fuel consumption: 29.7 m/imp gal, 24.7 m US gal, 9.5 1 x 100 km
- Max speed: 87 mph, 140 km h
- Max power (SAE): 55 hp at 5100 rpm
- Max torque (SAE): 61 1b ft, 8.4 kgm at 3000 rpm
- Max number of engine rpm: 5500
- Specific power: 45 hp/l
- Power-weight ratio: 36.2 lb/hp, 16.4 kg/hp
- Useful load: 772 1b, 350 kg
- Acceleration: 0—50 mph (0-80 kmh) 15 sec
The Škoda Felicia was one of the few convertibles in the Eastern Bloc to be produced in large numbers. The appearance was considered successful at the time. A tightly tuned chassis and powerful exhaust sound had to underline the sporty character. The steering was indirect and the handling strongly oversteered. The engine was considered elastic, but not high-revving. Among the positive features was modest fuel consumption.
Production of the convertible ended in 1964 without replacement. The sporty model was succeeded by the Škoda 1100 MBX, a rear-engine coupé. The Felicia name was resurrected by Škoda from 1994 for the compact Škoda Felicia.In total of the original 14,863 450 and Felicias were produced.
Rating
Technical
-
Skoda 450 Felicia Maintenance and Service Guide (1957-1964)
Fuel: petrol, 95-100 oct
Engine oil change: 2.9 imp qt, 3.5 US qt, 3.3 1, SAE 20 (winter) 40 (summer), change every 1900 miles, 3000 km
Total lubricating system capacity: 3.1 imp qt, 3.7 US qt, 3.5 1
cooling system capacity: 5.7 imp qt, 6.9 US qt, 6.5 1.
Gearbox oil: 0.6 imp qt. 0.7 US qt. 0.7 1, SAE 90-140, change every 6200 miles, 10000 km
Final drive oil: 1.4 imp qt, 1.7 US qt. 1.6 1, SAE 90-140, change every 6200 miles, 10000 km
Greasing: every 600 miles, 1000 km, 11 points
Tappet clearances: inlet 0.006 in, 0.15 mm, exhaust 0.008 in, 0.20 mm
Valve timing: (inlet) opens 9° before tdc and closes 51° after bdc, (exhaust) opens 44° before bdc and closes 16° after tdc
Tyre pressure (normal load): front 20 psi, 1.4 atm, rear 24 psi, 1.7 atm.
Tyres: 5.90 - 15
Fuel tank capacity: 6.60 imp gal, 7.92 US© Motor car History
-
Skoda 450 Felicia Technical details and specifications (1957-1964)
ENGINE:
location front
4 stroke; cylinders 4, in line
bore and stroke: 2.84 x 2.95 in. 72 x 75 mm
engine capacity: 74.68 in, 1221 cu cm
compression ratio: 8.4:1 (option) 8:1
cylinder block: cast iron
cylinder head: light alloy
crankshaft bearings: 3
valves: 2 per cylinder, overhead, with push rods and rockers
camshaft: side; lubrication: gear pump, filter on by-pass
carburation: 2 Jikov 32 SOPc downdraft carburettors
fuel feed: mechanical pump
cooling system: water
TRANSMISSION:
driving wheels: rear
clutch: single dry plate
gear box: mechanical; gears: 4 + reverse
synchromesh gears: 2nd, 3rd, 4th
ratios: (1st) 4.27, (2nd) 2.46, (3rd) 1.59, (4th) 1, (Rev) 5.61
(option) Saxomat automatic clutch
gear lever location: steering column
final drive: spiral bevel; ratio: 4.78:1 (option) 5.25:1
CHASSIS:
backbone type
front suspension: independent, wishbones, coil springs, anti-roll bar, telescopic dampers
rear suspension: swinging semi-axles, laminated transverse upper arms, telescopic dampers.STEERING:
screw and nut
turns of steering wheel lock to lock: 3.5
turning radius (between walls): 17.7 ft, 5.4 mELECTRICAL EQUIPMENT:
voltage: 12 V
battery: 50 Ah
dynamo: 200 W;
ignition distributor: PalDIMENSIONS AND WEIGHT:
wheel base: 94.56 in, 2400 mm
front track: 47.28 in, 1200 mm
rear track: 49.25 in, 1250 mm
overall length: 160.16 in, 4065 mm
overall width: 63.04 in, 1600 mm
overall height: 56.33 in, 1380 mm
ground clearance: 6.9 in, 175 mm
dry weight: 1984 1b, 900 kg
distribution of weight (max load): 43% front axle, 57% rear axle© Motor car History
