Info
Opel Vauxhall Corsa C
![]() | |
Make: | Opel Vauxhall |
Production period: | 2000 to 2006 |
Class : | small car |
Body versions : | hatchback |
Engines: | Petrol engines : 1.0-1.8 liters |
The Vauxhall Opel Corsa C was from autumn 2000 to summer 2006 built by Opel and General Motors a small car , which replaced his predecessor the Corsa B .
History
For the market launch in November 2000 Opel offered the Corsa C as a 1.0-liter with 58 hp, 1.2-liter with 75 hp and 1.4-liter with 90 hp. The new EasyTronic, an automated manual transmission , was initially available only in conjunction with the 1.2-liter engine, and later for the 1.0- and the 1.4-liter gasoline engine, and the 1,3- liter diesel. The 1.3 CDTI is - at the time of its presentation - the smallest four-cylinder common-rail diesel engine in the world and is also available in the Opel Astra with 66 kW. This engine, developed with Fiat and used among others in the models Panda , Punto and Grande Punto , gave the Italians the title of Engine of the year 2005 .In February 2001 followed the 1.8-liter GSi with 125 hp.
From the beginning of 2001, there was a diesel with 1.7 liters displacement and turbocharger with intercooler . This had 75 hp. The ECO was also offered again - and with the same engine as the previous model.In the summer of 2002, a small facelift, whereby the Corsa C received a chrome clasp on the front grille and other little things were changed.
In August 2003, a larger the Corsa C was facelift , given mainly modified the bumpers in and the rear fog lamp is placed deeper. In addition, the headlights (ellipsoid headlights) and the chrome clasp in the grille have been changed.
The Corsa C was in October 2006 by the Corsa D replaced. Only in some countries, for example in Israel , Saudi Arabia , South Africa and Taiwan , the Corsa C was later replaced by a newer model. In South America exists with the Chevrolet Montana a pickup variant of the Corsa C.
The Opel Corsa Sedan , which was built by General Motors Egypt , even remained in production until 2009. Also in South America, the Corsa B is still being built as a classic parallel to the Corsa C. In Japan as well as in East Africa , the third generation of the Corsa is known as the Opel Vita .The Opel Corsa C, Tigra Twintop , Meriva and Combo used the same platform.
The equipment variants above the nameless basic equipment are: Cosmo, Comfort, Cool, Eco, Edition, Elegance, Enjoy, Fresh, GSi, Njoy, Selection, Sport, Sportsline, Black & Silver (for the 20th anniversary of the Corsa 2002, only 2002 copies made ).
After facelifting in the summer of 2003, the Corsa's 1.0 and 1.4 petrol engines were replaced by Twinport technology-Opel's fuel-efficient part- load technology, with two separate intake ports per cylinder, one of which can be closed by flaps. By using the "Twinport" system, the engine output of the 3-cylinder engine increased by 2 hp to 60 hp (Z10XE has 58 hp). Nevertheless, the consumption dropped and with economical drivingthe brand reached 4.5 l / 100 km. The 1.2-liter engine has 4 cylinders and made 75 hp (Z12XE).
Only from model year 2005, this engine was replaced by the corresponding twin port (Z12XEP: 80 hp). However, the 1.8 engine remained unchanged and is now also available, for example, in the model variant Sport. The GSi, however, became a mere model variant, now available with the 1.4, 1.8 and 1.7 CDTi engines. From the facelift there was the Isuzu engine 1.7 DTI (Opel designation Y17DT, 55 kW, 165 Nm) with common rail injection under the designation 1.7 CDTi (Opel designation Z17DTH, 74 kW, 240 Nm). The engine was also installed in the Astra H and in some Honda cars .Furthermore, the small diesel 1.3 CDTi with 51 kW was introduced at the same time, which is a Fiat Powertrain development.
Technical details
All engines meet the Euro 4 standard . Stars in the Euro-NCAP - Crash test 4.stars
Engines:
Petrol engines : 1.0-1.8 liters (43-92 kW)
Diesel engines : 1.3-1.7 liters (51-74 kW)
Length: 3839 mm
Width: 1646 mm
Height: 1440 mm
Wheelbase: 2491 mm
Curb weight: 930-1155 kg
Drive: Front wheel drive
Fuel Capacity: 44 litres
Turning Circle: 10m
Seats: 5
Unbraked Towing Weight: 450kg
Braked Towing Weight: 1000kg
Technical
-
Opel Vauxhall Corsa C EngineTechnical data
Petrol engine
parameter
engine
engine designation
1.0 12V ECOTEC
1.0 12V TWINPORTECOTEC
1.2 16V ECOTEC
1.2 16V TWINPORT ECOTEC
1.4 16V ECOTEC
1.4 16V TWINPORT ECOTEC
1.8 16V ECOTEC (GSi)
engine identification
Z10XE
Z10XEP
Z12XE
Z12XEP
Z14XE
Z14XEP
Z18XE
Construction period
09.2000-08.2003
08.2003-07.2006
09.2000-08.2004
09.2004-07.2006
09.2000-08.2003
08.2003-07.2006
02.2001-07.2006
cylinder
3
4
Displacement (cm³)
973
998
1199
1229
1389
1364
1796
Bore × stroke (mm)
72.5 × 78.6
73.4 × 78.6
72.5 × 72.6
73.4 × 72.6
77.6 × 73.4
73.4 × 80.6
80.5 × 88.2
compression
10.1
10.5
10.1
10.5
10.5
10.5
10.5
Power (kW (hp) at 1 / min)
43 (58) / 5600
44 (60) / 5600
55 (75) / 5600
59 (80) / 5600
66 (90) / 6000
66 (90) / 5600
92 (125) / 6000
Torque (Nm at 1 / min)
85/3800
88/3800
110/4000
110/4000
125/4000
125/4000
165/4600
Maximum speed (km / h)
155
157
170
175
180
179
202
Acceleration 0-100 km / h (seconds)
16.0
15.5
13.0
12.5
11.5
11.5
9.0
Fuel consumption city (l / 100 km)
7.2
6.9-7.1
8.2
7.8-8.0
9.8
7.9-8.1
10.8 to 11.0
Fuel consumption Country (l / 100 km)
4.7
4.4-4.6
5.2
4.6-4.8
5.7
4.7-4.9
5.6-5.8
Total fuel consumption (l / 100 km)
5.6
5.3-5.5
6.3
5.8-6.0
7.2
5.9-6.1
7.5-7.7
Total CO 2 emissions (g / km)
135
127-132
151
139-144
173
142-146
179-185
emission standard
Euro 3
Euro 4
Euro 4
Euro 4
Euro 3
Euro 4
Euro 3 / Euro 4
Performance , fuel consumption and CO 2 emissions are related to the five-speed manual transmission. Other gear types (eg automatic) can lead to other values.
Diesel
parameter
engine
engine designation
1.3 CDTI ECOTEC
1.7 DI ECOTEC
1.7 DTI ECOTEC
1.7 CD TI * ECOTEC
engine identification
Z13DT
Y17DTL
Y17DT
Z17DTH
Construction period
08.2003-07.2006
09.2000-08.2003
09.2000-08.2003
08.2003-07.2006
cylinder
4
Displacement (cm³)
1248
1686
1686
1686
Bore × stroke (mm)
69.6 × 82.0
79.0 × 86.0
79.0 × 86.0
79.0 × 86.0
compression
18.0
18.4
18.4
18.4
Power (kW (hp) at 1 / min)
51 (70) / 4000
48 (65) / 4500
55 (75) / 4400
74 (101) / 4400
Torque (Nm at 1 / min)
170 / 1750-2500
130 / 2000-3000
165/1800
240/2300
Maximum speed (km / h)
165
162
170
188
Acceleration 0-100 km / h (seconds)
14.5
14.5
13.5
11.5
Fuel consumption city (l / 100 km)
5.6-5.8
5.6-5.8
5.8
6.3-6.5
Fuel consumption Country (l / 100 km)
3.7-3.9
3.9-4.1
4.1
3.8-4.0
Fuel consumption total (l / 100 km)
4.4-4.6
4.5-4.7
4.7
4.7-4.9
CO 2 emissions (g / km)
119-124
126
127-132
emission standard
Euro 4
Euro 3
Euro 3
Euro 4
- The CDTI lettering of the 1.7-liter model differs from that of the 1.3-liter model by the red-colored letter TI.
