TVR 390SE

 (1984 to 1989)

Manufacturer	TVR
Also called	TVR 420SE
Production	1984 - 1989
Successor	TVR 400SE
Class	Sports car
Body style	2-door convertible
Layout	FR layout
Platform	TVR Wedge
Engine	TVR Power Rover V8
Transmission	5 spd manual
Related	TVR 350i
Designer(s)	Oliver Winterbottom

The TVR 390SE is a sports car designed and built by TVR. It was introduced in October 1984. It featured many novelties not found in other 'Wedge' TVRs before and was also the most powerful one yet. It never received British Type Approval, so technically speaking the 390SE was just a 350i with special equipment fitted.

History

TVR Engineering worked with Andy Rouse, a Rover Tuning specialist to produce a blueprinted engine, turning out an extra 85 bhp (63 kW; 86 PS), taking it to a claimed 275 bhp (205 kW; 279 PS). The engine achieved these numbers by using some very interesting improvements such as an increased capacity of the engine to 3,905 cc, high lift camshafts, gas flowed cylinder heads with large valves and Cosworth machined pistons. A stronger clutch, limited slip differential and wider Yokohama tyres were fitted to help get the extra power down onto the road.

The styling of the car was also improved - or at any rate made more aggressive - with a deeper front air dam, and a rear under body aerofoil. Subsequent updating saw the bodyshell gain flared wheelarches and different sills. Ventilated front disc brakes and fifteen inch wheels were part of the package as well. A Series 2 car appeared in 1988 with the most obvious difference being a rounder nose.

Production of the modified Rover V8 was handled by different engineering companies throughout the car's life with most units being produced by North Coventry Kawasaki (NCK); which company was subsequently purchased by TVR to become their in-house engine division, TVR Power. About 100 390SEs were built.

Owing to the United Kingdom 'Type Approval' rules, it was not economical for TVR to homologate the small-volume 390SE as a separate model from their more common '350i' so the customer was invoiced for the car and engine work separately. Therefore most 390SEs are officially registered as 3.5 litre cars.

PERFORMANCE
max power (DIN): 275 hp (202 kW) at 5,500 rpm
max torque (DIN): 270 1b ft, 37.3 kg m (366 Nm) at 3,500 rpm
max engine rpm: 6,000; 70.4 hP/l (51.7 kW/l)
power-weight ratio: 8.5 lb/hP (11.6 lb/kW), 3.8 kg/hp (5.2 kg/kW)
Fuel consumption: 20.9 m/imp gal, 17.4 m/US gal' 13.5 1 x 100 km.
max speeds: (l) 36 mph, 58 km/h; (Il) 62 mph, 100 km/h; (Ill) 88 mph, 142 km/h; (IV) 122 mph, 196 km/h; (V)
over 150 mph, 241 km/h

420SE

At the customer's request, further engine work could be performed taking the V8 to 4.2 L capacity - thus creating the '420SE' in the process, of which only seven were built in 1986 and 1987.These cars were development cars for the 4.2-litre V8 used in the later, wilder 420 SEAC. The SE, in addition to more restrained bodywork, also featured somewhat milder cams than did the SEAC. However, due to the development status and its being handbuilt, the specs of each 420SE built are likely to differ.
