Daihatsu YRV
![]() | |
Production period: | 2000 to 2005 |
Class: | Motorcar |
Body versions: | Small 4 door |
Engines: | 1.0–1.3 litres |
Length: | 3765mm |
Width: | 1620mm |
Height: | 1550mm |
wheelbase: | 2355mm |
curb weight: | 890-1002kg |
Turning Circle: | 8m |
Fuel Capacity | 40 litres |
The Daihatsu YRV minivan was produced for 5 years from August 2000 to July 2005 on the basis of the Sirion Storia subcompact.
History
The Daihatsu YRV was 3.77-meter-long car, which was only available as a five-door model The name is short for "Young Recreational Vehicle", had a rear seat bench that could be moved lengthways by 15 centimetres in the higher-quality CXL and CXS versions. The YRV was powered either by at first by a one-litre three-cylinder or a 1.3-liter four-cylinder in naturally K3-VE engine aspirated or turbo versions of the K3-VET engine internationally.; the power transmission to the front wheels took over a five-speed manual transmission or a four-speed automatic electronically controlled. All-wheel drive 4Trak was available on request.
The interior features a geometric dashboard layout with the instrument panel and the unique side window shape. The standard JDM car, "S pack", "Aero S pack", "Turbo", and "Turbo Panorama Pack (2WD car only)". ("CG" and 1.3 L / NA car with 5 Manual in addition to 4 Auto turbo car only has 4 Auto. The AT select lever NA is column shift and turbo is floor shift. Car with Manual mode in this case, only the steering switch can be operated in MT mode.
Engines
- EJ-VE
- K3-VE2
- K3-VE
- K3-VET
- K3-VET-R
In, 2001 For the JDM market the special model "Limited" series "S Edition". "Aero S Pack" and "Turbo Panorama Pack", and is equipped with multi-reflector halogen fog lamps, a seat lifter for driver's seat, and a 2DIN CD/MD/AM/FM stereo. In addition, the "Limited " is equipped with smoked glass, sliding and split folding rear seats, and rear door speakers, while the "Aero S Pack Limited" is equipped with crystal rear combination lamps (clear) and sliding and split folding rear seats. The latter is based on the CG, with coloured electric retractable door mirrors, full wheel caps, UV cut glass, rear wiper, driver's seat lifter, separate rear headrest, power windows, power door locks, keyless entry, impact sensing safety system, it is a complete specification equipped with a 2DIN CD/AM/FM stereo. The 1.3 L turbo cars becoming "Turbo G", "Parco Turbo", " 6th grade of Turbo R. "Parco Turbo" adopts a column shift in a turbo car. In addition, the 2WD vehicles of "Parco L" and "Parco S" have improved environmental performance.
- All-wheel drive system named "4Trak", available only with K3-VE; all other versions are equipped with 2WD.
- The YRV has an option for an electronically controlled 4-speed automatic transmission, with built-in "steer shift" function. YRV turbo comes only with that option.
- Foldable rear seats allow for the YRV to allocate more space for luggage.
By 2004 The vehicle model has been changed, and the "L" and "X" 2WD vehicles have been certified as "2005 standard exhaust gas 50% reduction level. By August 2005 is the end of production with last stock sold over the next few months.
1.3 Turbo Performance
Power | 127 bhp |
---|---|
Top Speed | 112 mph |
0-60 mph | 8.1 secs |
Torque | 170 Nm, 125 ft-lb |
CO2 Emissions | 165 g/km |
Euro Emissions Standard | 3 |
Miles Per Tank | 352 miles |
Engine Size | 1298cc |
---|---|
Cylinders | 4 |
Valves | 16 |
Fuel Type | Petrol |
Transmission | Automatic |
Gearbox | 4 Speed Auto |
Drivetrain | Front wheel drive |
The 1.3-liter turbo sometimes called the called "GTti" feature an air scoop on the bonnet, below which the intercooler was placed. In Europe was only available in yellow and silver, with some special models in black. Otherwise, the YRV was also available in Mars red, white, Caribbean blue metallic and silver rose metallic finishes.
Description
Technical
-
Daihatsu YRV Technical details and specifications (2000-2005)
Engine: 1.3L K3-VE
No. of cylinders 4/DOHC
Capacity 1298cc
Compression ratio 10:1
Firing order 1-3-4-2
Suitable for unleaded petrol Yes
Minimum octane rating RON 90
Ignition system Make Daihatsu
Air metering Type MAP
Combined ignition and fuel ECM Yes
Diagnostic socket Yes
Ignition coil supply voltage + with ballast 12,0V
Fuel pump delivery pressure 2,7-3,7bar
Injector 13,4-14,2 Ohm
Lambda sensor (Oxygen) heater 11,7-14,5 Ohm
Oil pressure 2,25 bar @ 4000rpm
Radiator cap 1,10bar
Thermostat opens °C 80Specifications
Daihatsu YRV
1000
Engine:
3-cylinder in-line engine (four-stroke), transverse at the front
Displacement:
989cc
Bore × Stroke:
72×81mm
Performance at 1/min:
43 kW
(58 hp) at 6000Max. torque at 1/min:
88 Nm at 3600
Compression:
10.0:1
Mixture preparation:
injection
valve control:
2 overhead camshafts, chain drive, 4 valves per cylinder
Cooling:
water cooling
Transmission:
5-speed gearbox
aW (standard with Turbo) four-speed automatic with steering wheel gearshift "SteerShift"
front-wheel drive, aW four-wheel drive (not with Turbo)Front suspension:
Wishbones, struts, coil springs, anti-roll bar
Rear suspension:
Torsion beam axle, coil springs
Brakes:
ventilated front disc brakes, rear drum brakes, ABS
Steering:
Rack and pinion steering, servo
Body:
Sheet steel, self-supporting
Track width front/rear:
1390/1405mm
Wheelbase:
2355mm
Dimensions:
3765×1620×1550mm
curb weight:
875kg
Top speed (factory):
150km/h
0-100 km/h (factory):
15.4s
Consumption (L/100 km, EU urban cycle):
6.9N
Consumption (L/100 km, extra-urban):
4.9N
Consumption (L/100 km, combined):
5.6N
Daihatsu YRV
1300
1300 Turbo
Engine:
4-cylinder in-line engine (four-stroke), transverse at the front
Displacement:
1298cc
Bore × Stroke:
72 × 79.7mm
Performance at 1/min:
64 kW
(87 hp) at 600095 kW
(129 hp) at 6400Max. torque at 1/min:
120 Nm at 3200
170 Nm at 2800
Compression:
10.0:1
8.5:1
Mixture preparation:
injection
Injection, turbocharger, intercooler
valve control:
2 overhead camshafts, chain drive, 4 valves per cylinder
Cooling:
water cooling
Transmission:
5-speed gearbox
aW (standard with Turbo) four-speed automatic with steering wheel gearshift "SteerShift"
front-wheel drive, aW four-wheel drive (not with Turbo)Front suspension:
Wishbones, struts, coil springs, anti-roll bar
Rear suspension:
Torsion beam axle, coil springs
Brakes:
ventilated front disc brakes, rear drum brakes, ABS
Steering:
Rack and pinion steering, servo
Body:
Sheet steel, self-supporting
Track width front/rear:
1390/1405mm
Wheelbase:
2355mm
Dimensions:
3765×1620×1550mm
curb weight:
890-945kg
from 890 kg
Top speed (factory):
165-175km/h
180+ km/h
0-100 km/h (factory):
11.2-13.1s
8.4s
Consumption (L/100 km, EU urban cycle):
7.6–8.5N
9.4N
Consumption (L/100 km, extra-urban):
5.1-5.5N
5.6N
Consumption (L/100 km, combined):
6.1–6.7N
7.0N
© Motor car History
-
Daihatsu YRV Maintenance and Service Guide (2000-2005)
Manual transmission oil grade 75W-85 SAE
Manual transmission oil litres 2,25
Automatic transmission fluid Type Dexron III
Automatic transmission fluid 1,9-5,0 litres
Differential oil grade - front 80W-90 SAE
Differential front/AT litres 1,0
Differential oil grade - SAE 75W-85 rear
Differential rear litres 1,3
Transfer box oil grade 80W-90 SAE
Transfer box 0,4 litres
Brake fluid Type DOT 3
Power steering fluid Type Dexron II
Road wheels Tighten 103±14 Nm
Parking brake travel No. of notches 4-7Engine: 1.3L K3-VE
Spark plugs Electrode gap 0,9-1,0 mm
Spark plugs Tighten 18±3 Nm
Spark plugs Original equipment Denso Type K20BR-S10
Spark plugs Make NGK Type BKUR6ETB-10
Valve clearance -INLET mm 0,13-0,23 check cold
Valve clearance -EXHAUST mm 0,31 check cold
Compression pressure 12,9bar
Drive belt tension - alternator/PAS/AC 6-7/7,5-11,5mm
Moderate climate grade SAE 10W-30 or 10W-40
Engine oil grade Cold climate SAE 5W-30
Engine oil grade Hot climate SAE 20W-50
Engine oil change with filter 3,2 litres
Engine oil Sump drain bolt Tighten 30±6 Nm
Cooling system total capacity litres 5,8 litresTightening torques Cylinder head
(Renew bolts Yes)
Stage 1 Tighten 20 Nm
Stage 2 Tighten 33±1 Nm
Stage 3 Tighten 90°© Motor car History
