Dacia 1300
![]() | |
Manufacturer | Dacia |
---|---|
Model years | 1969 to 1979 |
Assembly | Mioveni, Romania |
Predecessor | None |
Successor | Dacia Logan |
Class | Motor Car |
Body style | 4-door saloon 5-door estate 2-door coupé 2-door coupé utility (pick up) |
Layout | FF layout |
Engine | 1.3 L |
Transmission | 4-speed manual |
Wheelbase | 96.06 in, 244 cm |
Length | 170.87 in 434 cm |
Width | 1,636 mm (64.4 in) |
Height | 63.78 in, 162 cm |
Curb weight | 1,985 1b, 900 kg |
The Dacia 1300 was built from 1969 to 1979 in Mioveni, Romania.
History
The Dacia 1300 was a car manufactured during the Cold War by Romanian auto marque Dacia. "1300" represents the car's engine displacement. The first Dacia 1300 left the assembly line on 23 August 1969.
While Fiat have established close ties with the motor industries ofthe Soviet Union, Poland and Yugoslavia, Renault has been helping Rumania to build up modern car production facilities. The Renault 12 four-door saloon and five-door station wagon are built and marketed as the Dacia 1300. Construction is the same as on the highly successful French-built models, with 4 stroke; 4 cylinders 1,289 c.c. 54 b.h.p with Solex 32 EISA downdraught carburettor. The pushrod engine overhung in front, driving the front wheels with 4 speed, fully synchronized gearbox, independent front suspension by coil springs and wishbones and a rigid rear axle with coil springs, the weight distribution was 58.3% to front, and 41.7% at rear.
- PERFORMANCE
- max power (DIN): 54 hp at 5,250 rpm
- max torque (DIN): 65 1b ft, 9 kg m at 3,000 rpm
- max engine rpm: 6,000; 41.8 hp/l
- power-weight ratio: 36.8 lb/hp, 16.7 kg/hp
- Fuel consumption: 33.2 m/imp gal, 27.7 m/US gal, 8.5 1 x 100 km.
- max speeds: (1st) 30 mph, 48 km/h; (2nd) 45 mph, 73 km/h; (3rd). 68 mph, 110 km/h; (4th) 90 mph, 145 km/h
In addition the 1301 to the sedan and wagon versions of the original, there was also a coupé utility version, Dacia 1302.In 1979, Dacia presented the 1310, a revised version of the 1300, at the Bucharest Auto Show.On 21 July 2004 the last Dacia 1310 (saloon version), number 1,959,730, rolled out the gates of the Mioveni production facility, just one month before their 35th anniversary.
Description
Technical
-
Dacia 1300 Technical details and specifications (1969-1979)
ENGINE
location front
4 stroke; 4 cylinders, vertical, in line
Engine capacity: 78.7 cu in, 1,289 cc
bore and stroke: 2.87 x 3.03 in, 73 x 77 mm
compression ratio: 8.5:1
cast iron block, wet liners, light alloy head
5 crankshaft bearings
valves: overhead, slanted, push-rods and rockers
camshafts: 1, side
lubrication: gear pump, filter in sump 5.3 imp pt, 6.3 US pt
1 Solex 32 EISA downdraught carburettor
fuel feed: mechanical pump; sealed circuit cooling, liquidTRANSMISSION
driving wheels: front
clutch: single dry plate (diaphragm)
gearbox: mechanical; gears: 4, fully synchronized
ratios: 1st 3.455, 2nd 2.235, 3rd 1.478, 4th 1.036, rev 3.080
gear lever location: central
final drive: hypoid bevel
axle ratio: 3.770CHASSIS
integral
front suspension: independent, wishbones. anti-roll bar, coil springs/telescopic dampers
rear: rigid axle, trailing arms, A-bracket, anti-roll bar, coil springs/ telescopic dampers.STEERING
rack-and-pinion
turns lock to lock: 3.50.
turning circle (between walls): 35.4 ft, 10.8 mBRAKES
front disc (diameter 8.98 in, 22.8 cm), rear drum, rear compensator
swept area: front 157.2 sq in, 1,014 sq cm
swept area: rear 70.1 sq in, 452 sq cm
total 241.3 sq in. 1,466 sq cm.ELECTRICAL EQUIPMENT
12 V
36 Ah battery
40 A alternator
DIMENSIONS AND WEIGHT
wheel base: 96.06 in, 244 cm
front and rear tracks: 51.57 in, 131 cm
length: 170.87 in 434 cm
width: 63.78 in, 162 cm
height: 56.30 in, 143 cm
ground clearance: 4.41 in, 11.2 cm
weight: 1,985 1b, 900 kg
weight distribution: 58.3% front, 41.7% rear© Motor car History
-
Dacia 1300 Service Guide (1969-1979)
Fuel: 92 oct petrol
Oil: engine 5.3 imp pt, 6.3 US pt, 3 1, SAE 10W-40, change every 3,100 miles, 5,000 km
Coolant capacity: 8.8 imp pt, 10.6 US pt
Gearbox and final drive 3.5 imp pt, 4.2 US pt, 2 1, SAE 80 EP, change every 6,200 miles, 10,000 km
Greasing: none
Tappet clearances: inlet 0.006 in, 0.15 mm, exhaust 0.008 in, 0.20 mm
Valve timing: 22° 62° 60° 20°
Tyre pressure: front 23 psi, 1.6 atm, rear 26 psi, 1.8 atm.
Width of rims: 4.5"
Tyres: 145 x 330.
Carrying capacity: 882 1b, 400 kg
Fuel tank: 11 imp gal, 13.2 US gal, 50 1.© Motor car History
