Motor Cars
Russia
1950s 1960s

ZIL-111

ZIL-111 car (1958-1967)

Production:

1958 to 1967

Class:

Lucury car

Body versions:

limousine, sedan, convertible

Engines:

Gasoline:6 litres (147 kW)

Length:

6190 mm

Width:

2045 mm

Height:

1637 mm

Wheelbase:

3760 mm

Curb weight:

2815 kg



The ZIL-111 (Russian ЗИЛ-111) is a luxury passenger car of the Soviet manufacturer ZIL,built from the late 1950s to the mid 1960s.

History

The ZIL-111 was assigned luxury class and was intended for the highest government officials for a successor to the outdated ZIS-110. This was initially the prototype Moskwa, which united the previous chassis of the ZIS-110 with a new body.  After the first tests were very promising, the prototype was revised again. The first production vehicle left the production line by late 1958.

with a look of American car designs Like the predecessor sedans, the ZIL-111.With numerous changes over the years. The sedan served exclusively the Soviet leadership. It is powered by a V8 gasoline engine, which develops a power of 147 kW. For the transmission, a two-stage hydromechanical automatic is used, with which the car reaches a top speed of 170 km / h.

PERFORMANCE:ENGINE CAPACITY: 365.74 cu in, 5980 cu cm

  • Fuel Consumption: 13.1 m/imp gal, 10.9 m/US gal, 21.5 x 100 km;
  • Max Speed: 105.6 mph, 170 km/h
  • max power (SAE): 220 hp at 4200 rpm
  • max torque (SAE): 347 1b ft, 48 kgm at 1800/2000 rpm
  • max number of engine rpm: 4500
  • specific power: 36.8 hp/l
  • max speed in 1st gear: 53.4 mph, 86 km/h; max speed in 2nd gear: 105.6 mph, 170 km/h
    power-weight ratio: 24.5 lb/hp, 11.1 kg/hp

The rear axle is sprung with semi-elliptic leaf springs, the front axle with coil springs. The vehicles have power steering and drum brakes. Under the name ZIL-111A a model with air conditioning was built from 1959 to 1962. Also built by ZIL a convertible version with the name ZIL-111W. On average, only 10 to 12 ZIL-111 vehicles were built each year. By 1963 an externally highly modified variant was ZIL-111G produced. Also, the ZIL-111G   a version as a convertible from 1964, the ZIL-111D. To the visit of US President Dwight D. Eisenhower developed a special version Eduard Molchanov. Successor of all models was the ZIL-114.

ZIL-111 Technical details and specifications

Related items
Vehicles launched in 1958 | Luxury Cars

Technical

Technical
  • ZIL-111 Technical details and specifications (1958-1967)

    ENGINE:
    Fuel :petrol
    front, 4 stroke
    cylinders: 8, Vee-slanted'
    bore and stroke: 3.94 x 3.74 in. 100 x 95 mm
    engine capacity: 365.74 cu in, 5900 cu cm
    compression ratio: 10.5 : 1
    cylinder block: light alloy, wet linings
    cylinder head: light alloy
    crankshaft bearings: 5
    valves: 2 per cylinder, overhead. with push rods
    lubrication: gear pump. oil cooler
    carburation: K 113 downdraft 4-barrel carburettor
    fuel feed: mechanical pump
    cooling system: water.

    TRANSMISSION:
    driving wheels: rear
    gear box: automatic. hydraulic torque convertor with 2 elements and planetary gears with 2 ratios
    push button control
    ratio: 3.54 : 1.

    CHASSIS:
    box-type ladder frame
    front suspension: independent, wishbones, coil springs. anti-roll bar, telescopic dampers
    rear suspension: rigid axle. semi-elliptic leafsprings, telescopic dampers.
    Axle load front: 1660 kg
    Rear axle load: 1680 kg

    STEERING:
    recirculating ball.
    Turning circle: 15 m

    BRAKES:
    drum.

    ELECTRICAL EQUIPMENT:
    voltage: 12 V
    battery: 68 Ah
    dynamo: 500 W

    DIMENSIONS AND WEIGHT:
    wheel base: 148.03 in, 3760 mm
    front track: 61.81 in, 1570 mm
    rear track: 64.96 in, 1650 mm
    overall length: 237.40 in, 6030 mm
    overall width: 79.92 in, 2030 mm
    overall height: 64.57 in, 1640 mm
    ground clearance: 7.60 in, 193 mm
    dry weight: 5402 lb. 2450 kg

    © Motor car History

Service

Service
  • ZIL-111 Practical Instructions and Service Guide  (1958-1967)

    fuel: 95 oct petrol
    engine oil: 12.40 imp pt. 14.80 US pt. 7 1. SAE IOW-30, change every 2.500 miles, 4,000 km
    gearbox oil: 22 imp pt. 26.42 US pt. 12.5 1, automatic transmission fluid type A, change once a year
    final drive oil: 6 imp pt. 7.19 US pt. 3.4 1, SAE 80-90, change every 7,500 miles, 12,100 km
    greasing: every 1.250 miles, 2,000 km, 20 points
    spark plug type: 1800
    valve timing: inlet opens 16° before tdc and closes 64°5' after bdc, exhaust opens 52° before bdc and closes 29° after tdc
    normal tyre pressure: front 31 psi, 2.2 atm, rear 31 psi. 2.2 atm.
    tyres: 8.90 - 15, tubeless
    fuel tank capacity: 16.72 imp gal, 20.00 US gal, 76 1.

    © Motor car History
