Chevrolet Biscayne First generation
![]() | |
Model years | 1958 |
Class | Motor Car |
Assembly | United States, Canada, Australia |
Body style | two and four-door sedan |
Engine | 235.5 cu in (3.9 L) |
Transmission | 3-speed manual |
Wheelbase | 117.5" |
Length | 209.1" |
Width | 77.7" |
The Chevrolet Biscayne 1st generation was only built in 1958, the Biscayne was the successor to the Two-Ten.
History
There were only two bodies for the Biscayne: sedans with six seats and two or four doors, and the six or nine seat with five doors that were called Brookwood. Instead of the individual headlamps of the predecessor model were now under double headlights. features include Styling Body by Fisher sterling anodized aluminum body safety girder frame, full-coil spring suspension spherical front joints four-link rear suspension.
Ball-Race steering bonded brake linings. Anti-Dive braking. tubeless tires 14-inch wheels.3-point engine mounting system 30-ampere generator dual headlights .safety plate glass throughout, high-vision windshield, crank one-key type ventipanes .
The six-cylinder models were called Series 1500 and had the well-known from its predecessor in-line engine with 3,859 cm, which gave 145 hp (107 kW) at 4,200 rpm. In the 1600 series, six different V8 engines were available; Base was an engine with 4,638 cm, the at 4,600 rpm (136 kW) gave an output of 185 PS. On request and for an extra charge, more engines also available. A total 76,229 Chevrolet Biscayne 1st generation 2 door were still built in 1958.
Description
Technical
-
-Note: Chevrolet Biscayne 1st gen Advanced Maintenance and Repair Manuals available for registered users-
Type
capacity
compression
carburettor
Exhaust
power
RPM
[cm 3 ]
[:1]
[PS / kW]
Super Turbo-Fire V-8
4,638
9.5
quadruple
Easy
230/169
4800
Turbo Thrust V-8
5703
9.5
quadruple
Double
250/184
4400
Super Turbo Thrust V-8
5703
9.5
3 × double
Double
280/206
4800
Super Turbo Thrust V-8
5703
11.0
3 × double
Double
315/232
5600
Ram-Jet Fuel Injection V-8
4,638
9.5
injection
Easy
250/184
5000
